Grey Street Lighting Pole Fuse Box , Lighting Junction Box High - Performance

Name: Grey Street Lighting Pole Fuse Box Lighting Junction Box High Performance
Brand: HOUSEELE
Price: 1 USD

China Grey Street Lighting Pole Fuse Box , Lighting Junction Box High - Performance wholesale

Brand Name : HOUSEELE

Model Number : EKM2035

Place of Origin : CHIAN

MOQ : 300PCS

Price : Negotiable

Payment Terms : Western Union, MoneyGram, T/T, D/P, D/A, L/C,

Supply Ability : 10000pcs per month

Delivery Time : according to quantity

Packaging Details : Standed export carton

Product name : Fuse box

Model No : EKM2035

Color : Gray

Protection Level : IP43

Service : OEM,ODM

Power Source : Electricity

Contact Now

China street lighting fuse box with 290mm length

Product Description:

This connection box is intended to be installed in lighting columns at the connection between looped-through feeder cables and the luminaire components timers, residual current devices or the like can be integrated on DIN rails.

Technical Date:

Body Material	Impact resistant thermoplastic
Corrosion performance	All metal parts corrosion protected
Cover	Transparent fuse cover
Ingress protection	IP43
Class of Protection	II
Electrial performance	Input cable section: 16-35mm²
	Output cable section: 16-35mm²
	Branch feeder cable section: 2.5mm²
	Feeder cable current(A): 32A

Selection Cirteria:

For application inside of lighting columns	Pole diameter≥ 110mm
	Door size ≥ 90x300mm
4 sliding terminals for	2 cables 4-50 mm²
	3 cables 4-35 mm²
Optional fuses D II (E27)	up to 25A
Optional for standard installation devices on DIN-rail attachable up to 3 TE width(3x18mm),max height of devices 75mm.

Packaging and shipping:

FAQ:

Q:When can I get the quotation?

A:We usually quote within 24 hours.

Q:How long can I get the samples and lead time?
A: Samples for 3~7days. Goods for 7~15days.

Q:Do you checkout all your products before delivery?
A:Yes, we make products 100% checked before delivery.

Q:What is your terms of payment?
A: 30% advance payment/deposit by T/T, and 70% paid before shipment.
